Cloth multicolor embossing machine

  • Cloth multicolor embossing machine
  • Cloth multicolor embossing machine
  • Cloth multicolor embossing machine

Cloth multicolor embossing machine

    Payment Type: L/C,T/T,Western Union
    Terms of Trade: FOB,CIF,EXW
    Min. Order: 1 Set/Sets
    Delivery Time: 20 Days
    Packaging: Standard Export Wooden Case
    Productivity: 100 Sets
    Brand: JINYU
    Transportation: Ocean,Land
    Place of Origin: Dongguan,China
    Supply Ability: 100 Sets/Month
    Certificate: CE
    Port: Shenzhen,Guangzhou

Basic Info

Model No.: JY-B04

Type: Other

Feature: Automation, Precision, High Efficiency

Certification: CE

Condition: New

Customized: Customized

Warranty: 12 Months

Model: JY-B04

Usage: Embossed Label On Clothes/Fabric

Working Table Size: 300*400MM

Main Cylinder Diameter: 63MM

Transport System: Hydraulic Heating Press

Power Supply: 380V

Total Power: 10.2KW

Weight: 700kg

Machine Size: 1450*1450*1650MM

Workstation: 2

Product Description

Cloth multicolor embossing machine


Embossed Machine2486


Cloth multicolor embossing machine for producing the labels on all kinds of fabric, like the cotton, Polyester etc. The Cloth multicolor embossing machine can produce the embossing and debossing labels on the textiles. These years is very popular. Our machine have full automatic one and semi auto one, with the similar functions. According to different products, customers can choose the most suitable one.


Product Specification:


Model
JY-B04
Stroke
120MM
Work table size
300*400MM
Main cylinder diameter
63MM
Horse
3.0HP
Heating power
7.2KW
Machine size
1700*1450*1700MM
Machine weight
700KG


Features about Cloth multicolor embossing machine:

1) Mechanical optional hands move and automatic sliding table control platens fluctuation, timing forming automatic playback, operating more safety

2) Forming time from 0.1 S to 99.99 H arbitrary adjustable, convenient operation, with counting function

3) Intelligent PID output temperature controller, temperature fluctuation, a difference of 1 degree more accurate. Up and down the independent control heating;

4) Hydraulic system: 68 # anti-wear hydraulic oil, HOB type hydraulic cylinder oil pump Taiwan Shenyu, solenoid valve for Taiwan Changmao.

5) The pressure 1-10 t adjustable; Oil cylinder specifications: diameter 100mm * stroke 120mm * adjustable 50mm, 6 head can be operated at the same time

6) Machine's Middle for air pressure, the pressure is equipped with a filter gas cup surge, left and right is oil pressure type, pressure adjustable, 6 head can be operated at the same time.

7) Automatic delay shutdown function, mechanical more energy-efficient, hydraulic motor is 4 Kw, combined double flow pump, to ensure that the four hydraulic cylinder and pressure will not be significantly speed down

8) Oil cylinder and air cylinder have stroke limit device for producing high quality products to provide better security;

9) Mechanical matches a typhoon cooled chiller, as the middle pressure type cooling aluminum provide cold water cooling, cooling temperature from room temperature to 4 degrees arbitrary adjustable

10) On both sides of the hot platen for flat grinding hard chrome plate to ensure press flat, intermediate cooling plate for aluminum alloy panel

11) Mechanical have adjustable machine, automatic and manual three function transformation, with water inward and outward

IMG_7362IMG20170728151804(1)


Package&Shipment:

Package

Company View:

samples roomworkshop (2)

clientIndia1


  • 1
  • 2
  • 3
  • 4
  • 5


Dongguan Jinyu Automation Equipment Co., Ltd. is founded in 2000, located in xiangdong industrial area, mainly dealing with silicone, pvc trademarks gifts making equipment, in a short few years, from guangdong pearl river delta to whole coastal area of China, the area of Zhejiang and jiangsu and some inland cities, silicone products had been sold all of the world, jinyu equipment is all over this industrial, jinyu got the industry`s highly recognized. As to reduce the environmental damage, we found silicone silicone industrial, it is environment protection and no harm to human, it is the best choose. Jinyu researched and developed full automatic dispensing machine, special silicone&rubber dropping, full automatic vulcanizing machine, is the best foundation of the industrial, jinyu equipment have the features of labors saving, save electricity, saving management. Jinyu company sincerely forward all the regular and new customers visit, let us grow up together.
