250T Low Price Industrial Cooling Tower

	Model	Cell	DIMENSIONS			Fan (mm)	Motor (mm)	pressure kPa	Weight (KG)	Noise (16m)	DN1	DN2
			A	B	H
Standard Model	AF-80	80-C1	2280	2280	3535	1500	2.2	37	740	47.0	150	200
	AF-100	100-C1	2530	2530	3655	1800	4.0	38	1020	48.0	150	200
	AF-125	125-C1	2830	2830	3785	1800	4.0	38	1270	49.0	150	200
	AF-150	150-C1	3080	3080	3860	2000	4.0	39	1530	50.0	150	200
	AF-175	175-C1	3330	3330	4060	2400	5.5	40	1840	51.0	150	200
	AF-200	200-C1	3530	3530	4150	2800	7.5	42	2040	52.0	200	250
	AF-225	225-C1	3730	3730	4220	2800	7.5	43	2400	53.5	200	250
	AF-250	250-C1	3930	3930	4495	2800	7.5	44	2398	54.5	200	250
	AF-300	300-C1	4330	4330	4765	3400	11	45	3760	55.0	250	300
	AF-400	400-C1	4980	4980	5315	4200	15	49	5800	57.5	250	300
	AF-500	500-C1	5580	5580	5685	4600	18.5	50	6480	58.5	300	350
	AF-600	600-C1	6080	6080	5825	4600	22	52	7760	60.5	300	350
	AF-650	225-C3	3730	11030	4220	2800	7.5x3	43	7220	61.0	200x3	250x3
	AF-700	175-C4	3330	13080	4060	2400	5.5x4	40	7360	61.5	150x4	200x4
	AF-800	200-C4	3530	13880	4150	2800	7.5x4	42	8180	62.0	200x4	250x4
	AF-900	225-C4	3730	14680	4220	2800	7.5x4	43	9630	62.5	200x4	250x4
	AF-1000	200-C5	3530	17330	4150	2800	7.5x5	42	10230	63.0	200x5	250x5
	AF-1100	225-C5	3730	18330	4220	2800	7.5x5	43	12000	63.5	200x5	250x5
	AF-1250	250-C5	3930	19330	4495	2800	7.5x5	44	11990	64.0	200x5	250x5
	AF-1500	300-C5	4330	21330	4765	3400	11x5	45	18800	64.5	250x5	300x5
Moderate temprature Model	AFⅡ-80	80-C1	2280	2280	4035	1500	3.0	42	1140	56.0	150	200
	AFⅡ-100	100-C1	2530	2530	4155	1800	4.0	43	1330	57.0	150	200
	AFⅡ-125	125-C1	2830	2830	4285	1800	4.0	43	1620	58.0	150	200
	AFⅡ-150	150-C1	3080	3080	4360	2000	5.5	44	1880	59.0	150	200
	AFⅡ-175	175-C1	3330	3330	4560	2400	7.5	45	2380	60.0	150	200
	AFⅡ-200	200-C1	3530	3530	4650	2800	7.5	47	2940	61.0	200	250
	AFⅡ-225	225-C1	3730	3730	4720	2800	7.5	48	3150	62.0	200	250
	AFⅡ-250	250-C1	3930	3930	4995	2800	7.5	49	3450	63.0	200	250
	AFⅡ-300	300-C1	4330	4330	5265	3400	11	50	4160	63.5	250	300
	AFⅡ-400	400-C1	4980	4980	5815	4200	15	54	6350	64.5	250	300
	AFⅡ-500	500-C1	5580	5580	6185	4600	18.5	55	7180	65.5	300	350
	AFⅡ-600	600-C1	6080	6080	6325	4600	22	57	9820	65.5	300	350

57

Contact us if you need more details on Industrial Cooling Tower. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Cooling Tower、Counter Flow Cooling Tower. If these products fail to match your need, please contact us and we would like to provide relevant information.
